There are many sheet metal materials suitable for stamping processing. Sheet metal materials widely used in the electronic and electrical industry include:

1. Ordinary cold rolled plate SPCC

SPCC refers to the continuous rolling of steel ingots through cold rolling mills into steel coils or sheets of required thickness. There is no protection on the surface of SPCC, and it is easily oxidized when exposed to the air, especially in a humid environment, the oxidation speed is accelerated, and dark red rust appears. The surface should be painted, electroplated or other protection when in use.

2, galvanized steel sheet SECC

The substrate of SECC is general cold-rolled steel coil, which becomes electro-galvanized product after degreasing, pickling, electroplating and various post-treatment processes on the continuous electro-galvanizing production line. SECC not only has the mechanical properties and similar processability of general cold-rolled steel sheet, but also has superior corrosion resistance and decorative appearance. It is highly competitive and replaceable in the electronic products, home appliances and furniture markets. For example, SECC is commonly used in computer cases.

3. Hot-dip galvanized steel sheet SGCC

Hot-dip galvanized steel coil refers to the semi-finished product after hot-rolled pickled or cold-rolled, washed, annealed, immersed in a molten zinc bath at a temperature of about 460°C, and the steel sheet is coated with a zinc layer. After tempering, leveling and chemical treatment. SGCC material is harder than SECC material, has poor ductility (avoid deep drawing design), thicker zinc layer, and poor electric weldability.

4, stainless steel SUS301

The content of Cr (chromium) is lower than that of SUS304, and the corrosion resistance is poor, but it can obtain good tensile force and hardness after cold working, and the elasticity is better. It is mostly used for shrapnel springs and anti-EMI.

5, stainless steel SUS304

One of the most widely used stainless steels. Because it contains Ni (nickel), it has better corrosion resistance and heat resistance than Cr (chromium) steel. It has very good mechanical properties, no heat treatment hardening, and no elasticity. .
